DieseRC 433Mhz Universal Wireless Remote Control Switch DC 12V 1CH RF Relay Receiver Module with 2 Transmitters, EV1527 Learning Code Smart Home Remote Switch
DieseRC 433Mhz Universal Wireless Remote Control Switch DC 12V 1CH RF Relay Receiver Module with 2 Transmitters, EV1527 Learning Code Smart Home Remote Switch
DieseRC 433Mhz Universal Wireless Remote Control Switch DC 12V 1CH RF Relay Receiver Module with 2 Transmitters, EV1527 Learning Code Smart Home Remote Switch
- 【Great design】433Mhz RF wireless remote control switch.Stable and reliable performance with high reception sensitivity (> 97dBm). Radio frequency signal transmission.Strong signal can pass walls, floors, doors,board and so on.It can be controlled within 50 meters distance in open area. You can remotely operate every machine connect with the relay receiver through the remote control.
- 【Easy to use】Extremely easy to set up and reset. There are 4 operating mode(momentary/toggle/latched/delay mode) can be chosen.You can easily set up by yourself depends on your needs. The operating mode of the product is adjustable.This item has already been set up in latched mode.
- 【More Flexibility】This receiver adopts 10A relay, which can load high-power electrical appliances to ensure long-term stability control.There are 3 terminals(normally open, common, normally closed) for the wireless relay.
- 【Operational safety】The voltage of this receiver is DC 5V~30V, so DC 12V/ 24V / 30V is OK. The operation is very safe.The terminal is a screw buckle, convenient and safe.
- 【Multiplayer control】One receiver can store about 20 transmitters. So you can share the transmitters to family/ friends.All of you can remote control the device connect with the relay receiver. And one transmitter can control multiple receivers too.
| Brand: | DieseRC |
|---|---|
| Manufacturer: | DieseRC |
| Part Number: | WRGK38B |
| Isin: | ITPZHTV98VGH |
Out of Stock
In Stock
Backordered
Out of Stock
IBspot Buyer Protection
Shop confidently on IBspot, receive your item as described or your money back for eligible orders. Learn Program Terms
GUARANTEED SAFE CHECKOUT
-
MONEY BACK GUARANTEE
30 days money back guarantee, no additional fee charged.
-
EXCELLENT SUPPORT
We provide 24/7 online customer support via email.
-
Fast Shipping
One week domestic shipping. Global delivery to the US in 2 weeks.
Package include:
1x Relay Receiver
2x Transmitters (contain battery)
1x Product manual
Parameter:
-Receiver Working voltage: AC 5V~36V
-Quiescent Current: <5MA
-Max current: 10A
-RF frequency: 433MHz
-Working temperature: -30~+80
-Receiving Sensitivity: >97dbm
-Amount of storage remote controls: 20 pieces
-Support encoding: 1527 Learning code
-RF Operating mode: ASK superheterodyne wireless reception
-Receiving range: Open space is more than 50 meters
-Pin: N/L
- Operating mode: Momentary /Toggle/ Latched Mode
-Battery: 27A 12V(contain)
Usage(Operation Mode):
Momentary Mode:
1. Press and hold one button, relay “1” will turn on;
2. Release the button, this relay “1” will turn off.
Toggle Mode:
1. Press button “A”, relay “1” will turn on;
2. Press button “A” again, this relay “1” will turn off.
Latched mode:
1. Press button “A”, relay will turn on;
2. Press button “B”, relay will turn off.
Reset:
Press the learning button (on the Receiver) 8 times. succeed.
Note:
After reset, all the remote controls cannot work any more.
Setup
1. Press the learning button (4 times for Momentary mode, 2 times for Toggle mode). Wait for 3 seconds;
2. Press one button. Succeed.
Setup latched mode
1. Press the learning button 3 times. Wait for 3 seconds;
2. Press button “A” .
3. Press button “B” . Succeed.
Note: This item has already been set up in latched mode. "A" button for turn on, and "B" button for turn off.
1x Relay Receiver
2x Transmitters (contain battery)
1x Product manual
Parameter:
-Receiver Working voltage: AC 5V~36V
-Quiescent Current: <5MA
-Max current: 10A
-RF frequency: 433MHz
-Working temperature: -30~+80
-Receiving Sensitivity: >97dbm
-Amount of storage remote controls: 20 pieces
-Support encoding: 1527 Learning code
-RF Operating mode: ASK superheterodyne wireless reception
-Receiving range: Open space is more than 50 meters
-Pin: N/L
- Operating mode: Momentary /Toggle/ Latched Mode
-Battery: 27A 12V(contain)
Usage(Operation Mode):
Momentary Mode:
1. Press and hold one button, relay “1” will turn on;
2. Release the button, this relay “1” will turn off.
Toggle Mode:
1. Press button “A”, relay “1” will turn on;
2. Press button “A” again, this relay “1” will turn off.
Latched mode:
1. Press button “A”, relay will turn on;
2. Press button “B”, relay will turn off.
Reset:
Press the learning button (on the Receiver) 8 times. succeed.
Note:
After reset, all the remote controls cannot work any more.
Setup
1. Press the learning button (4 times for Momentary mode, 2 times for Toggle mode). Wait for 3 seconds;
2. Press one button. Succeed.
Setup latched mode
1. Press the learning button 3 times. Wait for 3 seconds;
2. Press button “A” .
3. Press button “B” . Succeed.
Note: This item has already been set up in latched mode. "A" button for turn on, and "B" button for turn off.
