Mitsubishi Electric MSO-T10 1.5 kW 200 V AC 200 V 1a Non-reversible electromagnetic switch (Main circuit voltage 200V) (Operating voltage: AC200V) (Auxiliary contact 1a) (Screw, DIN rail mounted) NN
Mitsubishi Electric MSO-T10 1.5 kW 200 V AC 200 V 1a Non-reversible electromagnetic switch (Main circuit voltage 200V) (Operating voltage: AC200V) (Auxiliary contact 1a) (Screw, DIN rail mounted) NN
Mitsubishi Electric MSO-T10 1.5 kW 200 V AC 200 V 1a Non-reversible electromagnetic switch (Main circuit voltage 200V) (Operating voltage: AC200V) (Auxiliary contact 1a) (Screw, DIN rail mounted) NN
- Can be used for motor starting, stopping and protecting burns
| Brand: | 三菱電機(MITSUBISHI) |
|---|---|
| Manufacturer: | 三菱電機(MITSUBISHI) |
| Part Number: | WZFPIOG |
| Isin: | IYRJJIRIOR38 |
Out of Stock
In Stock
Backordered
Out of Stock
IBspot Buyer Protection
Shop confidently on IBspot, receive your item as described or your money back for eligible orders. Learn Program Terms
GUARANTEED SAFE CHECKOUT
-
MONEY BACK GUARANTEE
30 days money back guarantee, no additional fee charged.
-
EXCELLENT SUPPORT
We provide 24/7 online customer support via email.
-
Fast Shipping
One week domestic shipping. Global delivery to the US in 2 weeks.
Features:
Representative Rated 11A (AC3 Class AC200V) AC Operated Charging Protective Cover
DIN Rail Mounting, Screw Mounting, Thermal 2 Elements.
The smaller electromagnetic contactor makes the electromagnetic opener smaller at a number of ratings.
Standard fitting terminal covers reduces inventory and reduces cover cost
Of course, it also improves the safety of the charging part.
Ideal for motor overload and restraint protection
[Standard Certification / Compliant]
Partially compatible
Partially compatible
Partially compatible
Partially compatible
Product Name: Non-reversible electromagnetic closure.
Model Number: MSO-T10 1.5kW 200V AC200V
Motor Capacity: 1.5 kW
[Standard three-phase motor voltage] 200V
Operating Coil Voltage: AC 200 V
[Auxiliary contacts] 1a
Type: Electromagnetic closure.
[Product (electromagnetic switcher)] Non-reversible electromagnetic closure
[Series] MS-T
Model Name: MSO-T10
[Reversible Driving] Impossible (non-reversible)
[Rated Capacity [kW].
AC 200 - 220 V, 2.2
AC 380 - 440 V, 2.7
AC 500 - 550 V, 2.7
[Three-phase cage motor (AC-4 grade)]
AC 200 - 220 V, 1.5
AC 380 - 440 V, 2.2
AC 500 - 550 V, 2.7
[Rated working current [A].
AC 200 - 220 V, 11
AC 380 - 440 V, 7
AC500-550V 6.
[Three-phase cage motor (AC-4 grade)]
AC 200 - 220 V, 8
AC 380 - 440 V, 6.
AC500-550V 6.
[Main Contact]
A contact: 20
[Contact configuration] 3a
[Auxiliary Contacts]
AC 110 V 6.
AC 220 V, 3.
AC550 V 1.2
[DC24V] 3
[DC 110V] 0.6
[DC220V] 0.3
[Open heat dissipation current] 10
[Contact Configuration]
Standard (special): 1a (1b)
[Performance]
AC 220 V, 110
AC 440 V 90
AC 220 V, 88
[AC440V] 72
[Mechanical Durability [1000]
[Electrical Durability [100%]
AC-3 grade... 200
[Opening and closing frequency] 1800
[Operation Coil]
Operating Voltage Type: AC
[Instant Input [VA] 47
[Input Constant (VA)] 7
Power Consumption: 2.2 W
Thermal Relay Specifications: 2 elements included (overload and restraint protection).
[Surge Absorption for Operation Coil] None
[Terminal Cover]
Standard terminal cover: Yes.
Wire streamlined terminal function... None
[Product Installation Method] Screws, DIN rails
Note 1: The rated current is the maximum current that satisfies the performance of the rated working voltage.
Note 2 The input of the operation coil, the power consumption is the average value when the 220V 60Hz is applied to the AC 200V coil.
Note 3: The number of closed/shut off current capacity can be opened and closed 50 times each (JIS C8201-4-1).
Representative Rated 11A (AC3 Class AC200V) AC Operated Charging Protective Cover
DIN Rail Mounting, Screw Mounting, Thermal 2 Elements.
The smaller electromagnetic contactor makes the electromagnetic opener smaller at a number of ratings.
Standard fitting terminal covers reduces inventory and reduces cover cost
Of course, it also improves the safety of the charging part.
Ideal for motor overload and restraint protection
[Standard Certification / Compliant]
Partially compatible
Partially compatible
Partially compatible
Partially compatible
Product Name: Non-reversible electromagnetic closure.
Model Number: MSO-T10 1.5kW 200V AC200V
Motor Capacity: 1.5 kW
[Standard three-phase motor voltage] 200V
Operating Coil Voltage: AC 200 V
[Auxiliary contacts] 1a
Type: Electromagnetic closure.
[Product (electromagnetic switcher)] Non-reversible electromagnetic closure
[Series] MS-T
Model Name: MSO-T10
[Reversible Driving] Impossible (non-reversible)
[Rated Capacity [kW].
AC 200 - 220 V, 2.2
AC 380 - 440 V, 2.7
AC 500 - 550 V, 2.7
[Three-phase cage motor (AC-4 grade)]
AC 200 - 220 V, 1.5
AC 380 - 440 V, 2.2
AC 500 - 550 V, 2.7
[Rated working current [A].
AC 200 - 220 V, 11
AC 380 - 440 V, 7
AC500-550V 6.
[Three-phase cage motor (AC-4 grade)]
AC 200 - 220 V, 8
AC 380 - 440 V, 6.
AC500-550V 6.
[Main Contact]
A contact: 20
[Contact configuration] 3a
[Auxiliary Contacts]
AC 110 V 6.
AC 220 V, 3.
AC550 V 1.2
[DC24V] 3
[DC 110V] 0.6
[DC220V] 0.3
[Open heat dissipation current] 10
[Contact Configuration]
Standard (special): 1a (1b)
[Performance]
AC 220 V, 110
AC 440 V 90
AC 220 V, 88
[AC440V] 72
[Mechanical Durability [1000]
[Electrical Durability [100%]
AC-3 grade... 200
[Opening and closing frequency] 1800
[Operation Coil]
Operating Voltage Type: AC
[Instant Input [VA] 47
[Input Constant (VA)] 7
Power Consumption: 2.2 W
Thermal Relay Specifications: 2 elements included (overload and restraint protection).
[Surge Absorption for Operation Coil] None
[Terminal Cover]
Standard terminal cover: Yes.
Wire streamlined terminal function... None
[Product Installation Method] Screws, DIN rails
Note 1: The rated current is the maximum current that satisfies the performance of the rated working voltage.
Note 2 The input of the operation coil, the power consumption is the average value when the 220V 60Hz is applied to the AC 200V coil.
Note 3: The number of closed/shut off current capacity can be opened and closed 50 times each (JIS C8201-4-1).
