U.S. SOLID ZINC-ALLOY SOLENOID VALVE
FEATURES
- Quick Reaction: The USS-ZSV solenoid valve features a quick reaction ability and is able to be started with zero pressure.
- Direct Acting: Built with direct acting design, the magnetic valve has strong resistance to impurities in the medium.
- High Cost-performance: This zinc-alloy solenoid valve offers the same performance and less cost as brass in regular usages.
- High Flow: The congenital structure of this solenoid valve make it a higher flow capacity than pilot-operated solenoid valve.
- Applications: This water valve has wide applications including house water, laundry equipment, industrial water control, pumps and so on.
SPECIFICATIONS
| Brand | U.S. SOLID |
| Model | USS-ZSV00009 |
| Thread size | 1/4" |
| Flow aperture | 2.5 mm |
| Body material | zinc alloy |
| Gasket / diaphragm / seal material | NBR |
| Operation type | direct lift valve |
| Operation mode | normally closed |
| Voltage | AC 110 V |
| Power rating | 22 VA |
| Suitable media | water, oil, diesel fuel, kerosene etc. |
| Operating pressure | air/water: 0 ~ 8 bar (0 ~ 116 psi); oil: 0 ~ 5 bar (0 ~ 72 psi) |
| Flow value | 0.23 Cv |
| Temperature range | 14 ~ 176 ℉ (-10 ~ 80 ℃) |
OVERHEATING WARNING
- Not designed for continuous operation(not a 100% duty cycle). While energized, under normal operating conditions, solenoid valve will get HOT. The coil will reach a maximum temperature of about 176℉ (80℃), which is fully complied with national standard JB/T7352-2010. If energized continuously for more than 8 hours the coil may burn.
MORE OPTIONS
| Voltage | Thread size | |
| JFZSV00007 | DC 12 V | 1/4" |
| JFZSV00008 | DC 12 V | 3/8" |
| JFZSV00001 | DC 12 V | 1/2" |
| JFZSV00002 | DC 12 V | 3/4" |
| JFZSV00003 | DC 12 V | 1" |
| JFZSV00009 | AC 110 V | 1/4" |
| JFZSV00010 | AC 110 V | 3/8" |
| JFZSV00004 | AC 110 V | 1/2" |
| JFZSV00005 | AC 110 V | 3/4" |
| JFZSV00006 | AC 110 V | 1" |
| JFZSV00011 | AC 24 V | 1/4" |
| JFZSV00012 | AC 24 V | 3/8" |
| JFZSV00013 | AC 24 V | 1/2" |
| JFZSV00014 | AC 24 V | 3/4" |
| JFZSV00015 | AC 24 V | 1" |
SHIPPING
- All orders will ship from Ohio or Nevada within 1-2 business days of payment. Delivery may be delayed due to carrier delays and/or other issues.
- All of our customers are very important to us, if you have a delivery or quality problem, please do not open a case but contact us promptly via eBay message, we will try our best to resolve it with you.
RETURN POLICY
- Returns are accepted within 30 days of the buyer receiving the item. Buyer is responsible for return shipping if it's not our fault. We will issue a refund within 2 business days of receiving the returned item.
- Returned items must be in their original condition, custom items cannot be returned.
